Satec PM290 Reference Guide

3
Table 1-1 Reply to Host Request Type '0'
FIELD OFFSET
(BYTES)
LENGTH
(BYTES)
DESCRIPTION CONFIGURATION
1 0 4 Voltage L1 NNN.,
2 4 4 Voltage L2 N.NN, NN.N, .
3 8 4 Voltage L3 NNN
4 12 5 Current L1
5 17 5 Current L2 NNNN, NN.NN
6 22 5 Current L3
7 27 6 Power L1 SNNNNN,
8 33 6 Power L2 WNN.NN,
WNNN.N
9 39 6 Power L3 WNNNN.
10 45 4 Power Factor L1
11 49 4 Power Factor L2 T.NN
12 53 4 Power Factor L3
13 57 6 Total Active Power SNNNNN,
WNN.NN,
WNNN.N
WNNNN.
14 63 4 System Power Factor T.NN
15 67 6 Active Energy NNNNN,
NNN.NN,
NNNN.N,
NNNNN.
16 73 5 Unbalanced Current NNNN
NN.NN
17 78 4 Frequency NN.N
18 82 6 Reactive Power L1 WNN.NN,
SNNNNN,
19 88 6 Reactive Power L2 WNNN.N,
20 94 6 Reactive Power L3 WNNNN.
21 100 6 Apparent Power L1
0NNNNN,
22 106 6 Apparent Power L2 NNN.NN,
NNNN.N,
23 112 6 Apparent Power L3 NNNNN.
24 118 6 Reactive Energy WNNNNN,
WNN.NN,
WNNN.N,
WNNNN.
25 124 6 Total Reactive Power SNNNNN,
WNN.NN,
WNNN.N,
WNNNN.
26 130 6 Total Apparent Power 0NNNNN,
NNN.NN,
NNNN.N,
NNNNN.
