SATEL PERFECTA-T 13
6.7 User menu
Enter the code and press to get access to the user menu. The functions you can run
will be displayed. The list of available functions depends on your rights, as well as on the
state and configuration of the system.
In order to quit the function and/or user menu, press . The keypad will quit the menu
automatically, if 2 minutes have elapsed since the last keypress.
6.7.1 Navigating through the menu and running functions
To navigate throughout the menu, you can use the arrow keys or number shortcuts. You can
also combine the two methods. The cursor shows the submenu you can enter / function
you can run.
Using the arrow keys
1. Using the
and keys, find the required submenu or function.
2. Press
or to open a submenu (use the key to go back to the main menu)
or run a function.
Using the number shortcuts
Most submenus and functions are designated by numbers. To find these numbers, refer to
section “User functions list”. Using the number keys, enter the number of submenu / function
to enter the submenu / run the function. You can enter at once a sequence of several digits
(corresponding to successive numbers of submenus and functions) to quickly run the
selected function.
For example, to start the zone inhibiting function, enter the user menu and then press
, where:
- entering the 4.ZONE BYPASSES submenu,
- running the 1.INHIBIT function.
Remember that the sequence of digits which starts a function e.g. from the main menu
level will not start the same function from the submenu level.
6.7.2 Data editing
The editing method depends on the type of data. Having completed the editing, press
to save the changes. If you want to exit the function without saving the changes, press .
Selection from the single-choice list
In the lower line of the display, the currently selected item is presented. You can scroll the list
using the and keys.
Selection from the multiple-choice list
In the lower line of the display, one of the items you can choose from is presented. You can
scroll the list using the and keys. The following symbol is situated in the upper
right corner of the display:
– displayed item is selected / option is enabled,
– displayed item is not selected / option is disabled.
Press any number key to change the currently shown symbol for another one.
If you want to see the status of all items (these can be e.g. zones, outputs, options, etc.),
press or . The numbers around the display allow the items to be identified. Use the
and keys to move the cursor. After hovering the cursor over the selected item,
