Section 1: Introduction
LM Basic 408e/412e Operator’s Manual Page 1-7
Specification/
Model Name
LM408e and LM412e
Physical Characteristics
Dimensions W 430 mm x D 271 mm x H 321 mm (Standard)
Weight 13 Kg (for a standard configuration)
Power Supply Input voltage: AC100V - 120V or AC200V to 240V ±10%
Power Consumption 180W (peak)
Standards Compliance CE(NEMCO-GS), UL/c-UL(MET), FCC (Class B), EN55022 (Class B), En61000, CCC,
MIC
Energy Saving: International Energy Star Program
Environmental Conservation: Manufactured according to environment friendly processes
In-house equipment level: Class B conformance
Package Fall: ISTA-2A
Operating Environment Operational ambient temperature: 5 to 40 degrees Celsius
Operational ambient humidity: 30 to 80% (no condensation)
Ambient Storage temperature: -5 to 60 degrees Celsius
Ambient Storage humidity: 30 to 90% (no condensation)
(Paper, and carbon ribbon excluded)
