Section 7: Optional Accessories
Page 7-2 LM Basic 408e/412e Operator’s Manual
7.3 OPTIONAL ACCESSORIES: INTERFACE BOARDS
7.3.1 RS-232C board
7.3.2 High speed RS-232C board
Interface board
Connector Printer DB-25S (equivalent) (male)
Cable DB-25P (equivalent) (female)
Cable length shorter than 5m
Signal level High level ＋ 5 ～＋ 12V
Low level － 5 ～－ 12V
Interface board
Connector Printer DB-25S (equivalent) (male)
Cable DB-25P (equivalent) (female)
Cable length shorter than 5m
Signal level
High level ＋ 5 ～＋ 12Ｖ
Low leve － 5 ～－ 12Ｖ
ＤＳＷ１
DSW1
