Section 5: Interface Specifications
LM Basic 408e/412e Operator’s Manual Page 5-3
5.3 INTERFACE CARD DIP SWITCH SETTINGS (LAN)
The LM Series Local Area Network interface card (optional) contains DIP switches for initializing
LAN configuration, LAN printing configuration, and LAN card self-diagnosis. The DIP switch
functions are:
5.4 INTERFACE CARD DIP SWITCH SETTINGS (WIRELESS LAN)
The LM Series Wireless Local Area Network interface card (optional) contains DIP switches for
initializing LAN configuration, LAN printing configuration, LAN card self-diagnosis and wireless
mode settings. The DIP switch settings must be made before installing the card into the printer.
The DIP switch functions are:
Switch No. LM408e/412e LAN Interface Card function
1Reserved
2 Initializes LAN card configuration information
3 Prints LAN card configuration information (configura-
tion information such as the IP address will be printed)
4 Prints LAN card self-examination (results of LAN card
examination will be printed)
Switch No. LM408e/412e Wireless LAN Interface Card function
1 Reserved
2 Initializes LAN card configuration information
3 Prints LAN card configuration information (configuration information such as the
IP address will be printed)
4 Prints LAN card self-examination (results of LAN card examination will be
printed)
5 Wireless Communication mode OFF—OFF : 802.11 Ad hoc
OFF—ON : Infrastructure
ON—OFF : Ad hoc
ON—ON : Unused
6
