Section 3: Configuration and Operation
LM Basic 408e/412e Operator’s Manual Page 3-9
3.4 NORMAL MODES (CONT’D)
3.4.4 Print Speed
Pressing LINE repeated cycles through the various available
speeds. The slowest speed is 2ips, while the highest speed is 6ips.
The default speed for the LM Basic 408e is 4ips.
Press the FEED button to select a print speed. The screen for Pitch Offset appears.
3.4.4 Pitch Offset
This screen lets you adjust the pitch offset by up to +/- 49mm.
The default value is 0.
Press the LINE button to shift the cursor from left to right.
When the cursor is over the “+” or “-” symbol, press the FEED button to cycle it between “+” and
“-”. The cursor then moves one step to the right.
When the cursor is over one of the numeric digits, press the FEED button to cycle it between “0”
and “9” to form the first or second digit of the desired pitch offset value.
Finally, press the FEED button to proceed to the screen for Cancel Print Job.
3.4.5 Cancel Print Job
This screen lets you cancel the current print job and all received
data for the label.
Press the LINE button to switch the cursor between YES and NO.
When the cursor is over the desired option, press the FEED button to confirm the setting.
If you selected YES, the print job is cancelled, and the following
screen appears for about three seconds:
The screen then goes back to ONLINE status.
PRINT SPEED
2 3 4 5 6
PITCH OFFSET
+ 00mm
CANCEL PRINT JOB
YES NO
CANCEL PRINT JOB
COMPLETED
