2.1.1 PRINTER PART NAMES
Clear window and
fanfold-label Loading
Top Cover
Label Outlet
Front cover
(allows access to optional cutter unit, DIP switches
and potentiometers)
LINE/FEED/
Power
buttons and
LEDs
7-segment
Error Status LED
Release latch for Top Cover
Mini
Screwdriver
Label Holders
Thermal Print
Head assembly
Label Holder Release Knob
Platen Assembly
Label Sensor
Optional Cutter
