SATO D508 - The Rear Panel

Section 3: Configuration and Operation
Page 3-2 SATO D508/D512 Operator Manual
3.2 THE REAR PANEL
All of the printer cable connectors are located on the Rear Panel, as follows.
Fanfold-label Loading Slot
Remove this panel to route fanfold paper into the printer
Power
Connector
for DC power
input from the
supplied AC
Adapter
IEEE1284
Parallel
Interface
Connector
