Attributes
CONTROLS AND SIGNALS
On-Line LED Green
Power LED Green
Error LED Red
LED Display Panel 7-Segment Single Character
On/Off-Line Button Front Panel
Label Feed Button Front Panel
Power On/Off Button Front Panel
Self Diagnostics Head check
Paper end
Cover open
Test p r i n t
POTENTIOMETER ADJUSTMENTS
Adjustment Potentiometers VR1: Offset level (DIPSW6 = OFF)
VR1: Print darkness (DIPSW6 = ON)
VR2: Eye Mark
VR3: Gap sensor (to adjust the threshold)
VR4: Label pitch offset
DIP switches DIP-SW -1,2,3 : Operation mode(Print mode/Download mode)
DIP-SW -4 : Reserved (constantly OFF)
DIP-SW -5 : Head check (ON-Enabled / OFF-Disabled)
DIP-SW -6 : VR1 function switch
(ON-Print darkness level / OFF-Offset)
DIP-SW -7 : DATA dump (ON-HEX dump print / OFF-Normal print)
DIP-SW -8 : Reserved (constantly OFF)
INTERFACE CONNECTIONS
Parallel (Option) IEEE1284
Serial (Option) RS232C (up to 57.6K bps) Hardware Flow Control (Ready/Busy) Soft-
ware Flow Control (X-On/X-Off)
Bi-directional Status
USB (Option) USB Specification Version 1.1
LAN (Option) 10/100 Base-T
RFID (Option) TBA
Wireless LAN (Option) 802.11 b/g (internal)
*All specifications subject to change without notice.
