SATO M84PRO - Media; Ribbon; Sensing; Interface Modules

Section 2: Technical Data
M84Pro Service Manual PN: 9001111A Page 2-2
MEDIA
Minimum Width .87 Inches (22 mm)
Minimum Length
Continuous
Tear-Off
Cutter
Dispense
0.24 Inches (6 mm)
0.63 Inches (16 mm)
1.18 Inches (30 mm)
1.18 Inches (30 mm)
Maximum Width 5.0 Inches (125 mm)
Type Die Cut Labels, Fan-Fold, Tag Stock or Continuous
Maximum Caliper .008 Inches (.21 mm)
Maximum Roll Diameter 8.6 Inches (220 mm), Wound face inward
Minimum Core Diameter 3 Inches (76.2 mm)
RIBBON
Maximum Width 4.4 Inches (111 mm)
Length 1475 Feet (450 m)
Thickness 4.5 Microns, Wound face inward
SENSING
See-Through for labels or tags Movable
Reflective Eye-Mark Movable
Continuous Form Sensor not used.
INTERFACE MODULES
Parallel Port IEEE 1284 Standard
Serial Port RS232C (9600 to 57,6000 dps) Standard
RS422/485 (9600 to 57600 bps) Optional
Ready/Busy or X-On/X-Off Flow Control
Bi-Directional Status
Universal Serial Bus USB Adapter
Ethernet 10/100 Base T, 802.116 Wireless Wi-Fi
Data Transmission ASCII Format
PROCESSING
CPU 32 Bit RISC
FLash ROM 2 Mega-Bytes
SDRAM 16 Mega-Bytes
Receive Buffer 2.95 Mega-Bytes
Memory Expansion See Options and Accessories
