Section 8: Adjustment Procedures
M84Pro Service Manual PN: 9001111A Page 8-15
PRINT DARKNESS ADJUSTMENT
Print darkness is adjusted by use of the PRINT potentiometer located on the Operator Panel of
the front housing cover.
1 Turn the PRINT potentiometer to the center position.
2 Turn on the printeries press the LINE key to go off-line.
3 Press the LINE and FEED keys simultaneously.
4 Press the LINE key to advance the cursor to the desired option.
5 Press the FEED key to select the option.
6 Turn the printer off and then on again.
7 Begin printing test labels antedates the PRINT potentiometer as necessary to achieve the
desired results.
LCD DISPLAY: PRINT DARKNESS
1 2 3 4 5
NOTE: It may be necessary to repeat the procedure and selecting a different
print darkness setting from the operator panel.
