Section 5: Printer Configuration
M84Pro Service Manual PN: 9001111A Page 5-4
Receive Buffer Selection(DSW2-5): Selects the operating mode of the receive buffer. Refer to
the Interface Specifications section of this manual for more information.
If a 10/100BaseT LAN card is installed, DS2-5 has the following definitions:
Firmware Download (DSW2-6): Places the printer in the Firmware Download mode for
downloading new firmware into flash ROM.
Protocol Code Selection (DSW2-7): Selects the command codes used for protocol control.
Refer to the Selecting Protocol Control Codes section of the Technical Reference manual for
additional information.
.
DSW2-5 SETTING
Off Single Job
On Multi Job
DSW2
ON
OFF
12345678
DSW2-5 SETTING
Off ENQ Response
On Periodic Response
DSW2-6 SETTING
Off Disabled
On Enabled
DSW2
ON
OFF
12345678
DSW2-7 SETTING
Off Standard
On Non-Std
DSW2
ON
OFF
12345678
