Savant S2/2000 Deployment Guide Copyright © 2019 Savant Systems, LLC
009-1914-00 | 191231 6 of 24
4. Wiring and Connections
4.1. Power
Savant Hosts use an A/C power connection. Read and adhere to the warnings listed below:
SURGE PROTECTION!
Use a surge-protected circuit for all components and power supplies requiring 100/240V (AC 50/60 Hz) source power.
ELECTRICAL DISCONNECT!
The source power outlet and power supply input power sockets should be easily accessible, to disconnect power in the event of an electrical
hazard or malfunction.
Power Management Recommendations
Savant recommends a pure sine wave uninterruptible power supply (UPS) with the ability to gracefully shut down the Savant Host before the battery
runs out of power. Never remove power from the Savant Host before shutting it down. See Appendix B: UPS Recommendations for more information.
4.2. Ethernet
Wired Connection
The Savant Host communicates with other devices on the network via a cat 5e/6/7 Ethernet connection.
For more information on using Ethernet, refer to Appendix A: Network Requirements.
Wireless Connection (SHR-S2 only)
The S2 Host contains a wireless radio. This device can use used with a wireless connection. Provisioning can be done with the Savant SmartConnect
App. For more information see the SmartConnect Software Reference Guide on the Savant Customer Community.
4.3. Audio Output
Savant Hosts include a Digital Optical (TOSlink) audio output for use with the Audio Interrupt Service (AIS). Connection instructions may vary based
on the Savant Audio Matrix or 3rd party switcher in use. For more information on configuring an AIS service, refer to the Audio Interrupt Service
(AIS) Configuration for Doorbells - Application Note, available on the Savant Customer Community
