Rejecter 50 notes
Pocket Capacity
Stacker 100
Printer Serial *)
Baud 9600
Data 8
Stop 1
Parity None
Interface
Column 40
*) If the machine has optional SRL or P-OCR mode, default printer type is set to Parallel Port.
Set Speed of the machine
From the Function Main Menu, select the “SPEED”.
The machine offers with three speeds; 800 / 1000 / 1200 NPM (Notes per Minute). In sub menu,
press a numeric key to select a speed or you can select using UP/DOWN key and START key. In
COUNT mode, you can set the speed up to 1200NPM but in SINGL , FACE, ORENT or MIXED
modes, the machine works with maximum 750 NPM. Please refer to the below table to see the
compulsory maximum speed for each condition.
Mode Compulsory Maximum Speed
COUNT 1200 NPM
MXED / SINGL /
FACE / ORENT
About 750 NPM
SORT About 700 NPM
SRL About 400 NPM
