Specifications
Item Unit Specification
Size (W x D x H) mm
inch
312[W] x 321[D] x 289[H]
12.36”[W] x 12.72”[D] x 11.45”[H]
Weight Kg / lbs Approx. 15 / 33
Hopper capacity Notes Max. 500
Stacker capacity Notes Max. 200
Reject pocket capacity Notes Max. 70
Display Type Dot 128 x 64 Graphic LCD
Connectivity interfaces
2 RS232C Port, Parallel Port
(9 Pin D-SUB and Modular Jack)
Currencies available 1 (Available up to 5 currencies)
Banknote size range mm W: 100 ~ 185, H: 60 ~ 90
Banknote thickness
range
mm
0.08 ~ 0.12
Counting Speed Notes/min 800/1000/1200
Discrimination Mode MIXED/SINGL/SORT/FACE/ORENT/COUNT
Optional: P-OCR/B-CODE/B-MIX/SRL
Preset Batch Number 1 – 200
Counterfeit Detection MG (SB1000 ), UV (SB1000 -1ch. /SB-1100-
3ch), MR-Array (SB-1100), IR (SB-1100)
Power Requirements 90-240VAC, 50~60Hz
Power Consumption W Standby: 9, Operation: 70
Operational
requirements
0~50deg/30~85%RH (Non Condensing)
Notes:
- This machine specification can be changed without further notice to improve its reliability,
function or design.
- The contents of this user's guide can also be changed.
Printed November, 2008
Rev. 2010
