Miscellaneous
OPM 200 en-GB 90
© Scania CV AB 2020, Sweden
Checking and adjusting the
valve clearance
Special tool
Block the starting device. If the engine starts un-
expectedly, there is a serious risk of injury.
The engine must be cold when the work is car-
ried out.
Remember to remove the turning tool from the
flywheel after adjustment.
Carry out the working without pausing, so that
no step is overlooked.
Carry out a check and adjustment of the valve
clearances one more time after the first 500 hours
of operation. After this, adjustment according to
the regular interval takes place, which is every
2,000 operational hours.
Number Designation Illustration
99 309 Turning tool for rotating the flywheel from below
2 402 509 Turning tool for rotating the flywheel from above
Other tools
Torque wrench, 0-50 Nm
Waterproof felt-tip pen
0.45 and 0.70 mm feeler gauges
Flash light
Mirror
