Other
1.
Remove exhaust gas temperature sensor (1).
Use 2 290 856 17 mm, Special sleeve, slot-
ted, 1/2" if necessary.
2. Loosen the differential pressure sensor’s har-
ness-to-component connector (2).
3. To facilitate fitting, use a marker pen to mark
the position of the particulate filter. Make a
mark on the oxidation catalytic converter in
line with the particulate filter connections for
the differential pressure sensor.
4. Remove the V-clamp at the particulate filter
outlet (1) and the V-clamp holding the end
plate (2). Remove the end plate (3).
5. Support the particulate filter with a jack or
similar.
