OPM 250 en-GB 24
© Scania CV AB 2022, Sweden
Starting and running
Bypass of the SCR system
If the SCR system has been activated and needs
to be bypassed in an emergency, this can be done
manually using the handle on the exhaust routing
valve.
Proceed as follows:
1. Remove the pin.
2. Remove the bolt.
3. Pull the handle to the Open position. See il-
lustration.
4. Lock the handle in the open position using
the pin and the bolt.
