Cooling system
OPM 360 en-GB 53
© Scania CV AB 2017, Sweden
5.
Fit the charge air pipe and the hose clamps.
6. Fit the crankcase ventilation hose.
7. Fit the catwalk:
– Loosely fit the protective plate to the
charge air pipe. Tighten the screws later.
– Fit the protective casing. Tighten the
screws later.
– Fit the catwalk with screws.
– Tighten all screws. The protective plate
and protective casing must be tightened to
a tightening torque of 15 Nm (11 lb-ft).
