1. Specifications
The Scanmaskin 650 is available with different power inputs and some options regarding
wet grinding. This is described in the different sections later on in this chapter.
1.1 Electrical specifications
To find the specifications that apply to your machine, check the information plate on the
electrical cabinet door.
Never connect the Scanmaskin 650 to any other voltage or number of phases
than described in this specification.
The power source must be fused according to “External fuse” in this specifica-
tion; also the cables used must be marked and rated in accordance with the fuse
used. Failure to comply with the correct fuses may cause fire or injuries.
Power choice
1
400 V 3~
2
230 V 3~ 230 V 1~
Power 7.5 kW (10 hp) 7.5 kW (10 hp) 4 kW (5 hp)
Current 15.3 A 27 A 29 A
Voltage 380 – 400 V 3~ 200 – 240 V 3~ 200 – 240 V 1~
Frequency 50/60 Hz ± 5% 50/60 Hz ± 5% 50/60 Hz ± 5%
External fuse
3
16 A 32 A 32 A
Power inlet
4
IEC 60309 3P+N+E
400V 16A
IEC 60309 3P+E
250V 32A
IEC 60309 2P+E
250V 32A
Partnumber 560040 560019
Table 11 Electrical specifications
All models are CE-marked.
If using a generator see “2.6.2 Using a generator”
1.2 Sound and vibration
Sound & vibration test in accordance with EN ISO 4871:2009, EN ISO 5349-1:2001
Measuring Tool: Lutron VB-8206SD
SoundTest: Vibration meter VB-8206SD
Testing is done with 50% speed and 100% speed
Tools on the machine: pcs type Pirahna and metallbound tools type
Bauta #30/40 blue soft
1 This refers to different power choices. Note that a Scanmaskin 650 made for one choice of power
must be used with that particular choice.
2 Standard
3 Maximum current for the fuses used in the power source (i.e. the distribution box).
4
This is the standard inlet used. Machines sold outside of EU will be shipped either with a local standard inlet or an adapter.
40
