SCANMASKIN 650 - Page 66

Scanmaskin 650 Grinding head
Pos Art nr. Denomination Qty
1 560110 Washer 40x5 1
2 560116 Spring Steel disc 1mm Grinding Head 4
3 570136 Seal VA-50 Grinding Head 1
4 580160-24 Central Hub, Grinding Head Scanmaskin 650 1
5 590012 Tool Head 220mm / 9” Scanmaskin 650 / SM28 1
6 910030 Bolt M8x16 1
7 910093 Rubber Damper 1
8 910103 Bolt M10x30 1
9 910109 Bolt Machine head M10 4
10 910197 Nord Lock for M10 bolt 1
11 580162 Seal 5mm Grinding Head Central Hub 1
Art no.
Description
Qty.
560106
Cover plate, upper
1
560107
Cover plate, lower
1
560510
Belt pulley, center
1
560511
Belt pulley bush, center
1
560512
Belt pulley, grinding spindle axis
3
560513
Belt pulley bush, grinding spindle axis
3
560514
Toothed belt
1
560515
Gear wheel with parallel key hub
1
560515
Gear wheel with parallel key hub
1
560516
Gear rim
1
560519
Gear barrel
1
560521
Grinding spindle axis
3
560523
Center axis
1
570021
Bearing shell, center, fixed
1
570022
Bearing shell, center, upper rotating
1
570023
Bearing shell, center, lower rotating
1
570024
Center axis
1
570025
Bearing shell, grinding spindle axis
6
570027
Cover plate, center
1
570072
Bushed gear wheel
2
570080
Grinding spindle hub
3
570081
Distance nipple Scan on
9
570082
Fastener, grinding spindle hub
3
570084
Cover plate, grinding spindle
3
570085
Distance plate, grinding spindle hub
3
570087
V-ring
3
66
