Schaeffler OPTIME
Combination of machines and
sensors
1)
Please consult Schaeffler if your machine is not listed.
Application
1)
Other
charac-
teristic
Sensor
type
Quan-
tity
Mounting location
Electric motor ⬍ 0,5 m OPTIME 3 1 ■ Bearing position on motor
drive side
■ Centrally on the motor
■ In the centre at the base
of the motor
⬎ 0,5 m OPTIME 3 2 ■ Drive side and
non-driven side of motor
■ Base of drive side and
non-driven side of motor
Fans Overhang OPTIME 3 1 ■ Plummer block housing
Between
bearings
OPTIME 3 2 ■ Plummer block housing
Directly
coupled
OPTIME 3 1 ■ Drive side of motor
Compressor – OPTIME 5 2 ■ Bearing position
Plummer block
bearings
– OPTIME 3 1 ■ Bearing position
Pump – OPTIME 5 2 ■ Bearing position
Geared motor ⬍ 0,5 m OPTIME 5 1 ■ Gearbox
⬎ 0,5 m OPTIME 3
OPTIME 5
1
1
■ Motor
■ Gearbox
Extruder – OPTIME 3 2 ■ Bearing position
Calenders – OPTIME 3 2 ■ Bearing position
Belt drive – OPTIME 3 2 ■ Bearing position
Saws – OPTIME 5 1 ■ Saw blade bearing
arrangement
Shaft – OPTIME 3 1 ■ Bearing housing
Gearbox – OPTIME 5 2 ■ Input and output
