Technical data
Technical data, gateway
Nameplate
The nameplate with the serial number (S/N) is located on the side of
the housing. Beneath this is a QR code, in which the serial number is
embedded.
Technical data, gateway
Designation Value Unit
Communication
Wirepas Mesh (ISM band) 2,4 GHz
2G, LTE CAT M1
(other options available with installed local
LTE stick: GSM, UMTS, LTE)
– –
WiFi 2,4 GHz
Ethernet RJ45 – –
SIM card format Micro-SIM (3FF) –
Electrical characteristics
Power consumption 30 VA
Power supply AC 85 to 264 V
Frequency 47 to 440 Hz
Ambient conditions
Protection class IP66 –
Operating temperature –20 to +50 °C
Storage Temperature –40 to +85 °C
Humidity 20 to 90 %
Dimensions, mass
Length 180 mm
Width 130 mm
Height 81 mm
Mass
⬇
1,2 kg
Certificates
CE (EU directive 2014/53/EU), FCC,
SRRC, IC, RCM, Anatel, NTC, NBTC,
SIRIM, WPC
Current certifications
https://www.schaeffler.de/
std/1F8A
Figure 59
Gateway dimensions
OPTIME
130
180
81
