Installation and commissioning www.schaerer.com
DANGER!
Risk of electrocution!
Risk of electrocution!
Always observe the following points:
• The phase must be fused at the ampere value specified on the serial plate.
• It must be possible to disconnect the device from the mains power supply at all poles.
• Never operate a device with a damaged power cable. Have a defective power cable or plug
replaced immediately by a qualified service technician.
• Schaerer AG does not recommend using an extension cable. If an extension cable is nev-
ertheless used (minimum cross-section: 1.5 mm²), please comply with the manufacturer’s
specifications for the cable (operating instructions) and with applicable local regulations.
• Route the power cable in such a way that it does not pose a tripping hazard. Do not pull
the cable over corners or sharp edges, pinch it between objects or allow it to hang loosely
in open spaces. Do not position the cable over hot objects, and be sure to protect the cable
from exposure to oil and aggressive cleaning products.
• Never lift or pull the device by the power cable. Never pull the plug out of the socket by its
cable. Never touch the power cable or plug with wet hands. Never insert a wet plug into a
power socket.
Power requirements
Mains Power requirements
Fuse protec-
tion (on-site)
Connecting
cable con-
ductor
cross-sec-
tion
1L, N, PE: 220 – 240 V CA 50/60 Hz 2000 – 2200 W 10 – 16 A 3 x 1.0 mm²
1L, N, PE: 100 – 120 V CA 50/60 Hz 1800 – 2100 W 20 A 3 x 14AWG
2L, PE: 200 – 220 V CA 50/60 Hz 1700 – 1900 W 2x15 A 3 x 1 mm²
2L, PE: 200 – 220 V CA 50/60 Hz 2600 – 3200 W 2x15 A 3 x 1.5 mm²
CAUTION!
Risk of machine
damage!
Water connection/drain
Conditions
The machine can become damaged as a result of poor material and incorrect water val-
ues.
Always observe the following points:
• The water must be free of contaminants and the chlorine content must not exceed 100 mg
mg per litre.
• Do not connect the machine to pure reverse osmosis water or other aggressive types of
water.
• The carbonate hardness must not exceed 5 – 6°dKH (German carbonate hardness) or 8.9
– 10.7°fKH (French carbonate hardness), and the total hardness value must always be
greater than the carbonate hardness.
• The minimum carbonate hardness is 5°dKH or 8.9°fKH. The pH value must be between
6.5 and 7.
• Always use the new hose set (fresh water/waste water hose) supplied with the machine.
The machine must be connected to the water supply in accordance with applicable require-
ments and the regulations of the respective country. If the machine is connected to a newly
installed water pipe, the pipe and intake hose must be rinsed thoroughly to ensure that no dirt
gets into the machine.
The coffee machine must be connected to an installed drinking water line with a shut-off valve.
The machine is connected to the pressure reducing valve on the main water valve (set to
0.3 MPa (3 bar)) using the mounted pressure hose and the G 3/8" screw connection.
If the machine is connected to a drain, the supplied thermally stable drain hose must be con-
nected to the drip tray and the siphon. This hose must be firmly attached to the drain and slant-
ed at a downward angle (so that the water is able to drain).
BA SCV_EN
V06 | 11.2015
21
