142

Operating manual  VISATRON® Oil Mist Detector  VN2020 / VN2020 EX

Part number 183001  Version 3.0

MAINTENANCE AND REPAIR

1: (Old) VN2020 measuring head

3: Allen key, size 4

2: 8x neck collar bolts

1: VN2020 measuring head

NOTE

Risk of impact and crushing

 Hold the measuring head [] by hand while loosening the fixing screws.

 Remove the measuring head and send it back to Schaller Automation.

Remove the flat seal and dispose of the seal in accordance with local disposal

regulations.
