Scheppach DC100 User Manual

www.scheppach.com
GB
|
19
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating instructions before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
8. Assembly / Before commissioning
m ATTENTION!
Always make sure the device is fully assembled
before commissioning!
8.1 Installing the lter cartridge (10) with lter bag
(11), Fig. 3 - 5
• Insert the lter cartridge (10) into the lter bag (11).
(Fig. 3 + 4)
• Press the overhang into the lter cartridge (10). (Fig.
4)
• Now t the lter cartridge (10) on the engine housing
(1). (Fig. 5)
• Place the complete engine housing (1) on the con-
tainer (3) and lock the locking hooks (9).
8.2 Installing the suction hose (5), Fig. 6 + 7
• Fit the suction hose (5) with the hose clamp (8) on
the hose port of the container (3).
• Fit the other side of the suction hose (5) with the
hose clamp (8) and hose coupling (7).
9. Start up
m ATTENTION!
Always make sure the device is fully assembled
before commissioning!
9.1 Switching on/o󰀨, Fig. 1
• To switch on, set the ON/OFF switch (4) to position “I”.
• To switch the device o󰀨 again, set the ON/OFF
switch (4) to position “0”.
• Risk to health due to noise. The permissible noise
level is exceeded during operations. It is essential
that personal protective equipment, such as hearing
protection, is worn.
• Hazard due to electrical power, with the use of im-
proper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “safety in-
structions” and the “Proper use” are observed along
with the whole of the operating instructions.
Ensure careful storage of the safety instructions.
6. Technical data
Suction port, connection Ø 100 mm
Hose length 2000 mm
Air power 215 m³/h
Pressure di󰀨erence 25000 Pa
Filter surface 0.3 m²
Container volume 65 l
Weight 5 kg
Electric motor
220 - 240 V~
50/60 Hz
Rated input 1200 W
Motor speed 35000 min
-1
Technical changes reserved!
Noise and vibration
m Warning: Noise can have serious e󰀨ects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
7. Unpacking
m ATTENTION!
The device and the packaging material are not
children‘s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or su󰀨ocating!
• Open the packaging and carefully remove the de-
vice.

Scheppach DC100 Specifications

General

Cleaning type	Dry
Product color	Blue
Filter material	Paper
Container material	Metal
Power tool activation	Yes
Capacity	65 L
Hose length	2 m
Airflow (high speed)	215 m³/h
Connection nominal diameter	100 mm
Input power	1200 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Width	400 mm
Height	700 mm
Weight	10500 g
