Scheppach DP16VLS Translation Of Original Operating Manual

 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
GB І 23
• Residual risks can be minimised if the „safety in-
structions“ and the „Proper use“ are observed
along with the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the ma-
chine in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be xed between the clamps.
• Avoid accidental starting of the machine: the op-
erating button may not be pressed when inserting
the plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your drill press provides optimal per-
formance.
• Hands may never enter the processing zone when
the machine is in operation. Release the handle
button and switch off the machine prior to any op-
erations.
• Prior to any adjustment, maintenance or service
work disconnect the mains power plug!
Technical Data
Nominal input voltage 230-240 V~/50 Hz
Power rating 500 W (S2 15min)
Motor speed 1450 min
-1
Output speed (innitely
adjustable)
600 -2600 min
-1
Drill chuck mount B16
Drill chuck 3 - 16 mm
Dimensions of drill table 164 x 162 mm
Angle adjustment of
table
45°/0°/45°
Drill depth 50 mm
Pillar diameter 46 mm
Height 600 mm
Base area 290 x 190 mm
Weight 13,5 kg
Laser class II
Wavelength of laser 650 nm
Laser output < 1 mW
Noise and vibration values
The total noise values determined in accordance
with EN 61029.
sound pressure level L
pA
71 dB (A)
uncertainty K
pA
3 dB
sound power level L
WA
84 dB (A)
uncertainty K
WA
3 dB
Wear hearing protection.
The effects of noise can cause a loss of hearing.
Total vibration values (vector sum - three directions)
determined in accordance with EN 61029.
Safety instructions for handling batteries
1 Always make sure that the batteries are inserted
with the correct polarity (+ and –), as indicated
on the battery.
2 Do not short-circuit batteries.
3 Do not charge non-rechargeable batteries.
4 Do not overcharge batteries!
5 Do not mix old and new batteries or batteries
of different types or manufacturers! Replace an
entire set of batteries at the same time.
6 Immediately remove used batteries from the
device and dispose of them properly! Do
not dispose batteries with household waste.
Defective or used batteries must be recycled ac-
cording to Directive 2006/66 / EC. Give back bat-
teries and / or the device has been offered to the
collective facilities. About disposal facilities you
can inform by your municipal or city government.
7 Do not allow batteries to heat up!
8 Do not weld or solder directly on batteries!
9 Do not dismantle batteries!
10 Do not allow batteries to deform!
11 Do not throw batteries into re!
12 Keep batteries out of the reach of children.
13 Do not allow children to replace batteries without
supervision!
14 Do not keep batteries near re, ovens or other
sources of heat. Do not use batteries in direct
sunlight or store them in vehicles in hot weather.
15 Keep unused batteries in the original packaging
and keep them away from metal objects. Do not
mix unpacked batteries or toss them together!
This can lead to a short-circuit of the battery
and thus damage, burns or even the risk of re.
16 Remove batteries from the equipment when it
will not be used for an extended period of time,
unless it is for emergencies!
17 NEVER handle batteries that have leaked with-
out appropriate protection. If the leaked uid
comes into contact with your skin, the skin in
this area should be rinsed off under running wa-
ter immediately. Always prevent the uid from
coming into contact with the eyes and mouth.
In the event of contact, please seek immediate
medical attention.
18 Clean the battery contacts and corresponding
contacts in the device prior to inserting the bat-
teries:
Residual risks
The machine has been built according to the
state of the art and the recognised technical
safety requirements. However, individual residu-
al risks can arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.

Scheppach DP16VLS Specifications

General

Drilling	Yes
Screwdriving	-
Product color	Blue, Grey
Input power	500 W
Power source	AC
AC input voltage	230 - 240 V
AC input frequency	50 Hz
Idle speed (max)	- RPM
Chuck capacity (max)	16 mm
Drilling diameter in steel (max)	- mm
Product type	Bench drill press
Housing material	Steel
Drill table size (WxD)	160 x 160 mm

Weight and Dimensions

Depth	460 mm
Width	380 mm
Height	250 mm
Weight	15420 g
