Scheppach Tiger 2500 Translation From The Original Instruction Manual

10 english
Manufacturer:
Scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
GÜnzburger Straße 69
D-89335 Ichenhausen / BRD
Dear customer,
we wish you a pleasant and successful working experi-
ence with your new scheppach wet grinding machine.
According to the applicable product liability law the man-
ufacturer of this device is not liable for damages which
arise on or in connection with this device in case of:
• improper handling
• non-compliance with the instructions for use
• repairs by third party, non authorized skilled workers
• installation and replacement of non-original spare
parts
• improper use
• failures of the electrical system due to the non-
compliance with the electrical specications and the
VDE 0100, DIN 57113 / VDE 0113 regulations
Recommendations:
Read the entire text of the operating instructions prior to
the assembly and operation of the device.
These operating instructions are intended to make it eas-
ier for you to get familiar with your device and utilize its
in tend ed possibilities of use.
The operating instructions contain important notes on
how to work safely, properly and economically with your
machine and how to avoid dangers, save repair costs,
reduce downtime, and increase the reliability and work-
ing life of the machine.
In addition to the safety regulations contained herein, you
must in any case comply with the applicable regulations
of your country with respect to the operation of the ma-
chine.
Put the operating instructions in a clear plastic folder to
protect them from dirt and humidity, and store them near
the machine. The instructions must be read and care-
fully observed by each operator prior to starting the work.
Only persons who have been trained in the use of the
machine and have been informed on the related dangers
and risks are allowed to use the machine. The required
minimum age must be met.
In addition to the safety notes contained in the present
operating instructions and the special regulations of your
country, the generally recognized technical rules for the
operation of wood working machines must be observed.
General Notes
• When you unpack the device, check all parts for possi-
ble transport damages. In case of complaints the sup-
plier is to be informed immediately.
• Complaints received at a later date will not be acknowl-
edged.
• Check the delivery for completeness.
• Read the operating instructions to make yourself famil-
iar with the device prior to using it.
• Use only original parts for accessories as well as for
wearing and spare parts. Spare parts are available
from your specialized dealer.
• Specify our part numbers as well as the type and year
of construction of the device in your orders.
TIGER 2500
Scope of delivery
Grinding stone
Universal holder
Abrasive paste
Angle measurer 250
Leather honing disc
Operating instructions
Specications
Dimensions LxWxH mm
320 x 325 x 335
Tool rest ø mm
12
Grinding stone ø mm
250
Idle-running speed -
grinding stone 1/min.
90
Cutting speed m/sec.
1,2
Weight kg
16,3
Drive
Motor V/Hz
230 – 240 / 50
Input P1 W
200
Output P2 W
120
Motor speed 1/min.
1400
Operating mode
S1 100 %
Current rating A
1,0
Subject to technical modications!!
Safety Instructions
Information relating to your safety are highlighted with
this symbol in the present operating instructions. m
Operators’ Training
• Pass the safety instructions to all persons working with
the machine.
• The operator must be at least 18 years old. Trainees
must be at least 16 years old, but are only allowed to
use the machine under supervision.
• Persons operating the machine must not be distracted.
• Keep away children from the machine if it is connected
to the mains.
• Always wear tight clothes. Remove jewelry, rings, and
wrist watches.
• Observe all safety instructions and warnings on the
machine and maintain them in a readable state.
• Be careful when working with the machine: the rotating
grinding tool may cause injuries of ngers and hands.
Stability
• Make sure the machine is installed on a rm ground
with sufcient stability.
• Make sure the workplace is sufciently illuminated.
Mains Connection of the Machine
• Check the mains connecting lines. Do not use defec-
tive lines. See electrical connection.
• Pay attention to the direction of rotation of the motor
and the tools. See electrical connection.
• Installations, repair, and maintenance work relating to the
electric installation may only be performed by specialists.

Scheppach Tiger 2500 Specifications

General

Input power	200 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Idle speed (max)	- RPM
Multi-tool applications	Grinding

Weight and Dimensions

Depth	320 mm
Width	325 mm
Height	335 mm
