PRODUCT DESCRIPTION
30.30.01.01117/06 www.schmalz.com EN | 11
2 Product Description
2.1 Description
1) Control unit
2) Motor
3) Rotor shaft
4) Housing
5) Brake
6) Electrical controller
7) Gear unit
8) Limit switch
9) Control pendant
10) Suspension eye
11) Load hook
12) Chain box
13) End stop
14) Safety latch
1
2
3
4
5
Single chain
6
7
8
9
Fig. 3
Single chain
Dual chain
10
14
12
13
11
14
11
