OPERATION
30.30.01.01117/06 www.schmalz.com EN | 31
Risk of limbs being crushed or trapped when guiding the load on the
chain
Skin and fingers can become crushed or trapped between the chain links.
Always guide the load using the control handle on the Handy-Lift.
Rotating the operator handle can cause impermissible pulling on the
control cable
Control cable might tear off
Return the operator handle to its original position after each transport.
6.4.3 Remote Control (Option)
The remote control option is available for chain hoists for mains voltage of 400 V / 50 Hz without
frequency control.
Operation of the chain hoist without a view of the working area
Risk of injury in the working area!
When using the remote control always keep an eye on the working area.
In the event of interruptions to work, ensure that unauthorized persons cannot
operate the remote control transmitter.
Operating with the remote control:
