schunk.com XND.00005.022_A – 10/2018 27
2 General safety instructions
2.1 Intended use
The clamping device may only be used in accordance with the technical data and has been
designed for stationary application on milling machines in an industrial environment.
Using the device in accordance with the intended purpose includes compliance with the
commissioning, installation and operating instructions, and with the environmental and
service conditions as provided by the manufacturer.
The manufacturer accepts no liability for damage resulting from non-intended use.
2.1.1 Technical data
Weight:
KSG 100 Standard: 19.5 kg
KSG 125 Standard: 35.0 kg
KSG 160 Standard: 70.0 kg
For further data, please see the current catalogue >> Schunk stationary Workholding <<
2.2 Reasonably foreseeable misapplication
Any application that is not in accordance with the "Intended use" or exceeds such
intended use is considered not in accordance with the regulations, and is forbidden.
Any other use of the device is subject to confirmation from the manufacturer.
Examples of forseeable misapplication:
Clamping device used on rotating systems.
Clamping widely protruding workpieces.
Clamping workpieces with a weight of over 20 kg in vertical position without an additional
safeguard to prevent the workpiece falling out.
2.2.1 Alterations and modifications
In the case of unauthorised alterations and modifications of the clamping device, the
manufacturer's liability ceases and any warranty is voided.
2.2.2 Spare and wear parts and auxiliary material
Only use original parts or parts approved by the manufacturer.
Using spare and wear parts by third party manufacturers may lead to risk.
