SCHUNK KSG series User Manual

_________________________________________________________________________________________
schunk.com XND.00005.022_A – 10/2018 38
8.1 Parts list
Position
Part. No.
Designation
Quantity
10
GPS.100.002.11
GPS.125.002.11
GPH.160.015.11
Base plate
1
20
GPA.100.040.11
GPA.125.040.11
GPA.160.040.11
Standard reversible jaw, fixed
1
30
GPA.100.041.02
GPA.125.041.02
GPA.160.041.02
Standard reversible jaw, movable
1
40
GPS.100.007.11
GPS.125.007.11
GPH.160.005.11
Spindle nut
1
50
GPS.100.062.01
GPS.125.062.01
GPS.160.062.01
Mechanical force cassette
1
60
GPS.100.061.02
GPS.125.061.02
GPS.160.061.01
Spindle assembly
1
70
GPS.100.020.11
GPS.125.020.11
GPS.125.020.11
Coupling bolt
1
80
GPS.100.040.11
GPS.125.040.11
GPS.160.040.11
Protection plate for movable jaw
2
90
GPS.125.028.12
Type plate
2
100
GPA.100.025.01
GPA.125.025.01
GPA.160.025.01
Cover sheets, 1 set
1
110
GPS.125.070.03
Clamping lever
1
120
GPS.125.077.02
Knurled pin
1
130
XNN.10311.471
XNN.10311.523
XNN.10301.625
M10 x 35 12.9 int. hex. cylinder screw
M12 x 40 12.9 int. hex. cylinder screw
M16 x 50 int. hex. cylinder screw
8
140
XNN.10707.409
Int. hex. threaded pin, ZA M8 x 12
2
150
XNN.90000.080
XNN.90000.080
XNN.90000.060
Spring-loaded pressure piece
4
4
8
Positions in plain font are used for KSG 100
Positions in italic font are used for KSG 125
Positions in underscored font are used for KSG 160
