schunk.com XND.00005.022_A – 10/2018 33
4.2 Jaw range
The reliable function of the clamping device is significantly affected by the selection of the
correct jaws.
5 Servicing, cleaning, maintenance
The KSG does not require special servicing since heavily used parts are protected against
soiling.
5.1 General cleaning / lubrication
Remove the spindle assembly.
Do not remove any other parts.
Clean the base plate and spindle assembly.
Lubricate the guide components and spindle
weekly; in the case of heavy use, lubricate twice a
week.
