Basic safety notes
10 04.01|MPG-plus |en
Variant gripping force maintenance
WARNING
Risk of injury from objects falling during energy supply failure
Products with a mechanical gripping force maintenance can, dur-
ing energy supply failure, still move independently in the direc-
tion specified by the mechanical gripping force maintenance.
• Secure the end positions of the product with SCHUNK SDV-P
pressure maintenance valves.
WARNING
Risk of injury due to residual energy in the gripper because of
gripping force maintenance by springs!
WARNING
Risk of injury due to spring forces!
While disassembling uncontrollable moves of parts of the gripper
possible!
• For modules which clamp with spring tension or gripping
force, parts are under tension.
• Before decommissioning, make sure, that no residual energy
remains in the system.
2.7.1
