Assembly
14 04.01|MPG-plus |en
NOTICE
Damage to the guides in case of wrong assembly
The guides can break, if the mounting screws of the top jaws are
tightened too much.
• Observe maximum tightening torques of the following table.
• If possible hold/hold up to the top jaws during assembly so
that the forces on the guide are not too large.
mounting of the top jaws
Designation MPG-plus
16 20 25 32 40 50 64
Thread in top jaws M3
M4
M4 M5
M5 M6 M8
Maximum tightening torque for
the mounting screws [Nm]
1.2 3.1 3.1 6.1 6.1 10 25
top jaws
