USER MANUAL (Instruction for Use) SW 2.9
Safety
Version 2.9.7 dated 2020-12-23 Page 29 of 75
_
Further labelling of the equipment
Sign Explanation Where placed
Logo of SCHWIND eye-tech-solutions
Console
Warning label
Before opening disconnect mains
Bottom plate of
the console
Mains supply label 115V
Back side of the
console
Mains supply label 230V
Back side of the
console
Maintenance intervals for the next TSC
Two pieces:
On the console
– front label
and foot switch
