12.3 List of Replacable Cables and Components
Cables and components according to the following table are likely to affect compliance of EMC
and have to be replaced as specified.
Table 5. REPLACABLE CABLES AND COMPONENTS
Port Description Classification Cable type Cable
length
used
Cable length
maximum
AC Power
in
Mains cable AC power Unshielded 3 m ---
Motor out Motor supply cable signal/control Unshielded 2.5m ---
Foot
switch
Cable of foot switch signal/control Shielded 3.5m + 1m ---
Serial D-
Sub
Connector
Serial port (for
service purpose
only)
signal/control Shielded 1m 2m
