SCHWIND Carriazo-Pendular - User Menu

USER MANUAL (Instruction for Use) SW 2.9
Operation
Version 2.9.7 dated 2020-12-23 Page 51 of 75
_
Standard Messages Explanation / Action
“Ready”
XXX mmHg
Stable vacuum has been reached. Press foot pedals to move the
head or abort operation with the vac switch.
“Elevate vac! Min: XXX
mmHg”
XXX mmHg
Falling under the Min OP Vac-Parameter the system will start
beeping and ask for elevation of the vacuum via the vacuum
regulator.
“Osc. current: XX.X mA”
Max: 100 mA
Test of blade current prior to the cutting procedure in standstill.
The blade must be perfectly inserted and wet to be accepted for
the cut. This test is performed for max. 2 seconds without
pendulum movement which starts automatically after
successful testing.
“Osc. current: OK mA”
XXX mmHg
Head moves forward and cuts. The blade current indicates the
power consumption of the running blade.
“End stop reached!”
“Press reverse pedal!”
Head has reached the final stop position; you will hear an OK-
melody.
“Reversing to home pos!”
XXX mmHg
Head moves backwards and will automatically stop when
reaching the upright position. You will hear an OK-melody.
6.3.2 User Menu
The User Menu can be activated by pressing the ‘menu’ button. In the User Menu it is possible
to display and modify user parameters of the Carriazo-Pendular. The values can be modified by
pressing the ‘edit/store’ button and then pressing either the ‘up’ or ‘down’ button. The modified
value will be stored by pressing the ‘edit/store’ button again. The User Menu can be deactivated
by pressing the ‘menu’ button for a second time.
The messages shown in the User Menu are listed below:
Message Explanation
“Usermenu”
“Select with arrow keys”
Use up / down keys for navigation.
“Speed in forward”
X.X mm/sec
Setting of the cutting speed
STD: 5.0 mm / sec
MIN: 2.0 mm / sec
MAX: 5.0 mm / sec
“Speed in reverse”
X.X mm / sec
Setting of the reverse speed
STD: 5.0 mm / sec
MIN: 3.5 mm / sec
MAX: 5.0 mm / sec
