USER MANUAL (Instruction for Use) SW 2.9
EMC Guidance and Manufacturer’s Declaration
Version 2.9.7 dated 2020-12-23 Page 71 of 75
_
100% dip in U
T
for
250 cycles
100% dip in U
T
for
250 cycles
Power frequency
(50 / 60Hz)
magnetic field
IEC 61000-4-8
30 A/m 30 A/m Power frequency magnetic
fields should be that of a
typical commercial or
hospital environment.
NOTE 1: Electrostatic air discharge using ±15kV or more at the operator keys and the text
display on the Pendular console can cause the display to stop displaying text. To reset the
display switch the Pendular off and on again.
NOTE 2: Electrical fast transient of ±2kV or more on the main power supply cable can cause the
display to stop displaying text. To reset the display switch the Pendular off and on again.
NOTE 3: U
T
is the a.c. mains voltage prior to application of the test level.
Table 3: ELECTROMAGNETIC IMMUNITY (2)
Guidelines and declaration of conformity – electromagnetic immunity
(Equipment and systems that are not life-supporting)
The Carriazo-Pendular is intended to be used in the electromagnetic environment specified
below. The customer or the user of the Carriazo-Pendular should assure that it is used in such
an environment.
Immunity test IEC 60601 test
level
Compliance
level
Electromagnetic environment –
guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150kHz to 80MHz
6 Vrms in ISM
bands
3 V/m
80MHz to 2,7GHz
For special test
frequencies refer
to NOTE 6.
3 Vrms
150kHz to
80MHz
6 Vrms in ISM
bands
3 V/m
80MHz to
2,7GHz
a) Portable RF communications
equipment (including peripherals
such as antenna cables and external
antennas) should be used no closer
than 30 cm (12 inches) to any part of
the AMARIS,
including cables specified by the
manufacturer. Otherwise,
degradation of the performance of
this equipment could result.
b) Over the frequency range 150 kHz
to 80 MHz, field strengths should be
less than 3 V/m.
NOTE 4: At 80 MHz, the higher frequency ranges applies.
NOTE 5: These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
