29
7. Using a wrench, turn the inner portion (CP3) of the Crank
Puller clockwise. The Crank Arm with Plastics will slide off as it is
tightened.
Note: Be advised that it may take a lot of force to get the Crank Puller to
start to slide off the Crank Arm.
8. Installation is the reverse procedure.
Note: Installation does not require the use of the crank puller. Be
sure the tabs in the Top Shroud snap into the Main Assembly.
9. Dispose of the old parts.
10. Inspect your machine to ensure that all hardware is tight and
components are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
Image does not match your machine. For illustrative purposes only.
