42
6. Using a 6mm hex wrench, remove the four bolts that attach the Lift
Assembly to the Rail Assembly. Remove the Lift Assembly.
If you are only replacing the Lift Assembly, go to Step 10.
If you are replacing the Rail Assembly, continue to Step 7.
7. Using a 6mm hex wrench, remove the four bolts that attach the Rail
Assembly to the Frame Assembly.
Be aware that the Frame Assembly may be unstable and
slightly top heavy.
8. Remove the Rail Assembly.
The machine may be moved by one or more persons depend-
ing on their physical abilities and capacities. Make sure that
you and others are all physically fit and able to move the
machine safely.
NOTICE: This step may require two people.
9. Attach the new Rail Assembly to the Frame Assembly.
Note: Be sure Levelers are fully raised on Rail Assembly.
Be aware that the Frame Assembly may be unstable and
slightly top heavy. This step may require two people.
6mm
6mm
To Next Page
