SPECIFICATIONS
MECHANICAL REMOVAL/REPLACEMENT
11
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Align the knotch
indicator on the tube
with the 0 degree marking
Reattach the lever clamp, threaded rod,
clamp barrel and thumb nut previously
removed.
Step 6:
Align the knotch indicator on the tube
with the 0 degree marking on the angle
indicator clamp.
Step 7:
Place a small amount of Loctite 271 on
the threads of the set screw and use a 3/16
allen hex to reinsert it into the handlebar
tube.
Step 8:
271
