Step 3:
Lift the left pedal and center the belt
onto the clutch pulley. Verify that the
groove side of the belt is meshing with
the grooves of the pulley, then release the
pedal.
Belt
Step 4:
SPECIFICATIONS
rIghT BELT TEnSIon SprIng rEpLAcEmEnT
Follow the steps in the “Left Belt Tension Spring Replacement” section for the right spring (#A5458).
Reattach the covers and console according to the “Lower/Upper Cover” replacement procedure on page 31.
