SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
43
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Step 1:
SPECIFICATIONS
LEFT BELT TEnSIon SprIng rEpLAcEmEnT
Reattach the tension spring to the spring
tension link.
Hook belt loop here
Smooth side
Grooved side
Step 2:
Reattach the belt loop to the belt tension
spring.
