SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
Unhook belt loop
from here
Step 4:
Unhook the belt loop from the end of the
belt tension spring.
Step 5:
Detach the tension spring (#A5458) from
spring tension link (#A4768).
SPECIFICATIONS
rIghT BELT TEnSIon SprIng rEmovAL
Follow the steps in the “Left Belt Tension Spring Removal” section for the right spring (#A5458).
