SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
56
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Step 2:
Lift the left pedal to relieve the tension on
the return spring.
Spring tension
will be less
Lift left
pedal upward
While holding the pedal up remove the
pedal belt (#A5164) from the clutch pulley,
then gently let the pedal down to a resting
position.
Belt
Step 3:
Step 4:
Carefully walk the drive belt (#P5166)
off the large pulley turning in a
counterclockwise direction.
ATTENTION
Pinching points may occur when removing
the belt, please use caution.
To Next Page
