SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
57
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Step 6:
Disconnect the 2-pin brake cable from the
coil cable located at the front of the brake .
Step 5:
Disconnect the 3-pin brake cable from the
side of the brake.
ATTENTION
DO NOT PULL THE CABLE. Press the
release tab to disconnect the cable from
the brake, otherwise damage to the cable
housing may occur.
Step 7:
Use a 7/16 socket to remove the four
1/4”-20 nylock nuts (#1137018) and four
M6 at washers (#1140355) .
7/16 Socket
To Next Page
