REDUCER/CYLINDER VALVE RCV-2
3.
Withdraw U-Clip (6) and remove breathing hose (7) from reducer head (18).
4.
Remove foam ring (17) from reducer head (18).
5.
Remove O-Ring (8) from reducer head (18) using O-Ring Tool (I). Discard O-
Ring.
6.
Withdraw pin bearing (13) from reducer head (18).
7.
Withdraw actuator U-Clip (9) from reducer head (18).
8.
Withdraw actuator assembly (14) from reducer head (18).
9.
Withdraw spring (10) and relief valve (11) from port in reducer head (18).
Issue D 10. 2009
RCV-2
(Page 5)
