RCV-2 REDUCER/CYLINDER VALVE
CAUTION:
If the burst disc has been ruptured, the cylinder and valve should be examined
to determine the cause and to ensure that the cylinder and valve are safe to use.
4.4
REPLACING THE CONTENTS GAUGE O-RING AND
RESTRICTOR
Note:
Bracketed numbers in this Section e.g: (4) refer to components depicted in Assembly
Diagrams and Parts Lists 5.1 and 5.2.
1.
Remove reducer cap (5) and reducer head (18) as described in Section 4.1 of
this Module.
2.
Withdraw contents gauge U-Clip (37) and remove contents gauge (34) from
reducer body (27).
3.
Remove contents gauge O-Ring (36) from reducer body (27) using O-Ring Tool
(I). Discard O-Ring.
4.
Tap reducer body (27) GENTLY to release restrictor (35) from reducer body.
Discard restrictor.
RCV-2
(Page 8) Issue D 10. 2009
