REDUCER/CYLINDER VALVE RCV-2
2.
Use Instrument Screwdriver (G) to remove U-Clip (4) from hood connector (3)
and withdraw hose from connector.
3.
Use O-Ring Tool (I) to remove O-Ring (5) from hood connector (3). Discard O-
Ring.
4.
Lightly lubricate replacement O-Ring (5) with Krytox Grease (K) and fit onto
hood connector (3).
5.
Check to confirm that silencer (6) is clean and in good condition. Replace if
necessary.
6.
Use O-Ring Tool (I) to remove O-Rings (2) from port within reducer head and
hood connector. Discard O-Rings.
7.
Lightly lubricate replacement O-Rings (2) with Krytox Grease (K) and fit onto
hose ends.
8.
Insert hose end into port within hood connector (3) and secure in position with
U-Clip (4).
9.
Insert opposite hose end into port within reducer head and secure in position
with U-Clip (4).
Issue D 10. 2009
RCV-2
(Page 13)
